JHRXLK-300 SF6 Infrared Gas Leak Detection Temperature Imager

recommendation index：

Both gas imaging leak detection and infrared temperature measurement

Quickly identify and locate the source of leaks

Passive infrared imaging, no specific background required, no auxiliary light source required

Long-distance and fast scanning of large areas to meet the detection of unreachable points

Using refrigerated infrared detectors, it is possible to detect the leakage of sulfur hexafluoride very quickly, safely and accurately
High-definition, high-sensitivity pseudo-color image to display the infrared thermal spectrum of an object
Ideal for detecting SF₆ gas or chemical leaks in large work areas

Imaging performance and optical parameters	parameter
focal plane array	Cooling type infrared detector
wavelength range	10.3 ≤ 10.7μm
Measure
precision	± 1 ° C of the temperature range (0-100 ° C) or ± 2% of the temperature range reading (> + 100 ° C)
Temperature measurement range	-40℃～+50℃；+0℃～+250℃；+200℃～500℃
Temperature measurement method	Manual/automatic, can set the temperature measurement point, area (the highest temperature and the lowest temperature can be set in the area), isotherm, temperature difference, with sound alarm and color alarm, and automatically track the highest/lowest temperature point in real time
measurement analysis
point temperature measurement	10, including maximum/minimum/average
regional temperature measurement	5, including maximum/minimum/average
Line temperature measurement	5, including maximum/minimum/average
Circular area temperature measurement	3, including maximum/minimum/average
